HPE ProLiant ML110 Gen11 4510 12-core 1P 64GB-R MR408i-o 8SFF 2x480GB SSD 2x1000W RPS EU Server

Lifecycle

• Obsolete Date 04-03-2026

Specifications

• System fan features 2x Standard Fans
• Processor cache 30 MB L3
• Processor core available 12 core
• Memory type HPE DDR5 Smart Memory
• Expansion slots Default with 2 x16 PCIe 5.0 Slots and 1 x16 OCP3 slot.
• Accelerators Optional: Supports NVIDIA L4/RTX 4000 Ada Graphics Accelerator for HPE, pending configuration
• Processor number 1 processor included
• Processor speed 2.40 GHz
• Storage controller HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
• Optical drive type Optional. None ship standard.
• Network controller Embedded 2-Port 1GbE BCM5720 networking ports
• Warranty 3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of on-site support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://support.hpe.com/hpesc/public/docDisplay?docId=sd00004309en_us. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to the HPE website at https://www.hpe.com/support.
• Security UEFI Secure Boot and Secure Start support. Intel® Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Front bezel key-lock feature, Intrusion cable (Included), Padlock slot and Kensington Lock slot support.
• Power supply type 2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
• Infrastructure management Included: HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional: HPE iLO Advanced, HPE OneView Advanced (require licenses) and HPE Compute Ops Management. Refer to the iLO 6 User Guide
• Included memory 64 GB (2×32 GB, 5600 MT/s)
• Processor name Intel® Xeon® Silver 4510 (12 core, 2.40 GHz, 30 MB L3, 150W)
• Included drives 2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• Form factor 4.5U Tower. Optional standalone Tower-to-Rack conversion kit (P47394-B21) to convert the unit to a 5.5U Rack-mount server.

Quickspecs

• QuickSpecs (HTML)
• QuickSpecs (PDF)
• QuickSpecs
• QuickSpecs

Overview

Are you searching for an affordable tower server with enterprise-class reliability and performance to meet the requirements of your growing business? The HPE ProLiant ML110 Gen11 server is an enhanced single processor tower with performance, expansion, and security at an affordable price. It supports the 4th and 5th Gen Intel® Xeon® Scalable processor, HPE DDR5 SmartMemory with a maximum capacity of 1536 GB, 4 x16 PCIe Gen5 slots, 1 x16 OCP3 slot, eight large form factor (LFF) or 16 small form factor (SFF) disk drives. It can easily be converted to a rack using 5.5U of rack space. The HPE ProLiant ML110 Gen11 server also offers optional redundant fan and redundant power supply to satisfy automatic fail-over needs, making this the ideal server for small- to mid-sized businesses, and remote and branch offices.

What’s new

• Powered by 4th and 5th Gen Intel® Xeon® Scalable Processors that support up to 32 cores, 185W TDP.
• Increased memory bandwidth to 5600 MT/s[1] , performance and lower power requirements with up to 1.5 TB DDR5 memory capacity with 16 DIMM slots.
• Advanced data transfer rates from the PCIe Gen5 serial expansion bus, support up to 4 standard PCIe Gen5 x16 slots and 1 OCP 3.0 x16 slots.
• Includes HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly from anywhere.
• Supports hot-pluggable, high-availability, RAID1 protected M.2 NVMe boot option.
• Support NVIDIA RTX 4000 Ada Graphics Accelerator and L4 24GB PCIe Accelerator

Features

HPE ProLiant ML110 Gen11 server uses the silicon root of trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the Intel Processor that must be matched exactly before the server will boot. This verifies that malicious code is contained, and healthy servers are protected.

HPE ProLiant Gen11 servers continuously protect healthy servers at the edge by providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies and contains malicious code, with IDevID certificates installed by default.

HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of the operating system, application, data connections, and providing a fast path to bring a server back online and into normal operations.

From silicon to software, from factory to cloud, and from generation to generation, HPE ProLiant Gen11 is engineered with a fundamental security approach to defend against increasingly complex threats through an uncompromising commitment to constant security advancements that are built into our DNA.

Automate tasks for efficiency in deployment, instant scalability, and seamless, simplified support and lifecycle management, effectively reducing tasks and shortening maintenance windows.

These experiences are engineered and built into HPE ProLiant Gen11 servers, whether purchased as physical servers or consumed as-a-service using GreenLake Flex Solutions as your compute and storage demands grow.

Simplify and secure server management from edge to cloud with HPE Compute Ops Management. HPE Compute Ops Management is an as-a-service compute management experience that delivers greater simplicity, agility, and speed across your entire compute landscape, globally.

Trusted Security by Design: Uncompromising, Fundamental, and Protected

The HPE ProLiant ML110 Gen11 server comes with a complete set of HPE Services, delivering confidence, reducing risk, and helping customers realize agility and stability.

HPE Services simplify all stages of the IT journey. Advisory and Transformation Services professionals understand customer challenges and design an effective solution. Professional Services enable rapid deployment of solutions and Operational Services provide ongoing support.

Services provided under Operational Services include: HPE Flexible Capacity, HPE Datacenter Care, HPE Infrastructure Automation, HPE Campus Care, HPE Proactive Services and multi-vendor coverage.

HPE IT investment solutions help you transform to a digital business with IT economics that align to your business goals.

Benefit from real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.

Customized Performance for your Workloads: Accelerated, Open, and Efficient

The HPE ProLiant ML110 Gen11 server is an excellent choice for compute and data storage balanced workloads (IT infrastructure, Data Management, VDI, ERP/CRM) requiring outstanding performance, network and I/O bandwidth.

Harness advanced compute performance. HPE ProLiant ML110 Gen11 server is powered by 4th and 5th Gen Intel® Xeon® Scalable Processors that support up to 32 cores at 185W TDP.

Enjoy advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 4 x16 PCIe Gen5 and 1 x16 OCP slots to improve I/O throughput and reduce latency.

Utilize 16 DIMM slots for up to 1.5 TB DDR5 memory with increased memory bandwidth and performance, and lower power requirements.

Industry-leading Services and Ease of Deployment
Intuitive Cloud Operating Experience: Simple, Unified, and Automated

HPE ProLiant ML110 Gen11 servers are engineered for your hybrid world. HPE ProLiant Gen11 servers simplify the way you control your business’s compute—from edge to cloud—with a cloud operating experience.

Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a single console.

Compatible products

• Intel Xeon-Silver 4410Y 2.0GHz 12-core 150W Processor for HPE
• HPE 2.4TB SAS 12G Mission Critical 10K SFF BC 3-year Warranty 512e Multi Vendor HDD
• HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
• HPE 300GB SAS 12G Mission Critical 10K SFF BC 3-year Warranty Multi Vendor HDD
• HPE 1800W-2200W FS Ti Ht Plg PS Kit
• HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
• HPE 1TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD
• HPE 3.2TB SAS 24G Mixed Use SFF BC Multi Vendor SSD
• HPE SN1600E 32Gb Dual Port Fibre Channel Host Bus Adapter
• HPE 2TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD
• HPE LTO-8 Ultrium 30TB RW Data Cartridge
• HPE MR416I-P GEN11 SPDM STORAGE CNTLR
• HPE StoreEver LTO-7 Ultrium 15000 External Tape Drive
• HPE 4TB SATA 6G Business Critical 7.2K LFF RW 1-year Warranty Multi Vendor HDD
• Memorie RAM Server HPE Smart Memory Kit, 64GB DDR5, 4800Mhz, CL40
• Intel Xeon-Gold 5515+ 3.2GHz 8-core 165W Processor for HPE
• HPE 8TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty 512e Multi Vendor HDD
• HPE 16TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e ISE Multi Vendor HDD
• HPE StoreEver LTO-8 Ultrium 30750 Internal Tape Drive
• HPE StoreEver LTO-8 Ultrium 30750 External Tape Drive
• HPE T750 Gen5 INTL UPS with Management Card Slot
• HPE SN1610Q 32Gb 1-port Fibre Channel Host Bus Adapter
• HPE 7.68TB SATA RI SFF BC MV SSD
• HPE 8TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty 512e Multi Vendor HDD
• HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE 480GB SATA 6G Mixed Use SFF BC Multi Vendor SSD
• HPE C13 – C14 WW 250V 10Amp 2.0m Jumper Cord
• BCM 57414 10/25GbE 2p SFP28 Adptr
• HPE 5 Year Tech Care Basic ML110 Server Smart Choice Service
• HP OV 3yr 24×7 Supp Flex E-LTU
• Intel Xeon-Silver 4510 2.4GHz 12-core 150W Processor for HPE
• HPE 1 Mini SAS HD – 4 Mini SAS FO 4
• HPE SN1610Q 32Gb 2-port Fibre Channel Host Bus Adapter
• HPE 3.84TB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
• HPE 3 Year Tech Care Essential ML110 Svrs Smart Choice Service
• Intel Xeon-Gold 5416S 2.0GHz 16-core 150W Processor for HPE
• HPE T1000 Gen5 INTL UPS with Management Card Slot
• HPE 1.92TB SATA 6G Mixed Use SFF BC Multi Vendor SSD
• Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T Adapter for HPE
• HPE 5 Year Tech Care Essential ML110 Svrs Smart Choice Service
• HPE 1.92TB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• Memorie RAM Server HPE SmartMemory, 32GB DDR5, 5600Mhz, CL45
• HPE 960GB SATA 6G Mixed Use SFF BC Multi Vendor SSD
• HPE 600GB SAS 10K SFF BC MV HDD
• HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features
• HPE 12TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e Multi Vendor HDD
• HPE 1.8TB SAS 10K SFF BC 512E MV HDD
• Intel I350-T4 Ethernet 1Gb 4-port BASE-T Adapter for HPE
• HPE 20TB SATA 7.2K LFF LP ISE MV HDD
• HPE 4TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD
• HPE Proliant DL/ML Startup Service
• HPE Proliant DL/ML Install Service
• HPE 9.5mm SATA DVD-RW Optical Drive
• HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
• HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller
• HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
• INT XEON-G 6426Y CPU FOR HPE
• Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
• MLX MCX631102 10/25GBE 2P SFP28 ADPTR
• HPE 1TB SATA 6G Business Critical 7.2K LFF RW 1-year Warranty Multi Vendor HDD
• INT Xeon-G 5418Y CPU for HPE
• HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit
• HPE 4TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD
• HPE 960GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE 96W Smart Storage Lithium-ion Battery with 260mm Cable Kit
• HPE 960GB SAS 12G Mixed Use SFF BC Value SAS Multi Vendor SSD
• HPE LTO-7 Ultrium 15000 Internal Tape Drive
• HPE SN1600E 32Gb Single Port Fibre Channel Host Bus Adapter
• HPE LTO-7 Ultrium 15TB RW Data Cartridge
• HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features
• HPE SN1610E 32GB 2P FC HBA
• HPE MR216i-p Gen11 x16 Lanes without Cache PCI SPDM Plug-in Storage Controller
• Memorie RAM Server HPE Smart Memory Kit, 16GB DDR5, 2800Mhz, CL45
• HPE Mobile USB DVD-RW Optical Drive
• HPE LTO-9 45TB RW DATA CARTRIDGE
• Memorie RAM Server HPE Smart Memory Kit, 64GB DDR5, 5600 Mhz, CL45
• Memorie RAM Server HPE Smart Memory Kit, 32GB DDR5, 4800Mhz, CL40
• HPE PROLIANT ML110 GEN11 REDUNDANT FAN K
• HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features
• Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T OCP3 Adapter for HPE
• Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE
• HPE 16TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e ISE Multi Vendor HDD
• HPE 16GB 1RX8 PC5-4800B-R SMART KIT
• BCM 57412 10GBE 2P SFP+ OCP3 ADPTR
• Broadcom BCM57412 Ethernet 10Gb 2-port SFP+ Adapter for HPE
• HPE 3 Year Tech Care Basic ML110 Server Smart Choice Service
• INT XEON-S 4514Y CPU FOR HPE
• HPE LTO-6 Ultrium 6.25TB RW Data Cartridge
• HPE StoreEver LTO-7 Ultrium 15000 TAA-compliant Internal Tape Drive
• HPE 1 Mini SAS HD – 4 Mini SAS FO 2M Cbl
• HPE 240GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE 3.84TB SAS RI SFF BC VS MV SSD
• HPE MR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller
• HPE 960GB SATA 6G Read Intensive LFF LPC Multi Vendor SSD
• HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features
• HPE Smart Storage Hybrid Capacitor with 260mm Cable Kit
• HPE MR216i-o Gen11 SPDM Storage Cntlr
• HPE T1000 G5 NA/JP Tower UPS
• HPE 7.68TB SAS 12G Read Intensive SFF BC Value SAS Multi Vendor SSD
• Intel I350-T4 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
• HPE 12TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e Multi Vendor HDD
• HPE 1.2TB SAS 12G Mission Critical 10K SFF BC 3-year Warranty Multi Vendor HDD
• HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device
• HPE 9.5mm SATA DVD-ROM Jb Gen9 Kit

Documents

• An affordable tower server built with small and medium business needs in mind

DDR5 5600 MT/s memory is limited to support with 5th Gen Intel processors. The maximum memory speed is a function of the memory type, memory configuration, and processor model.
