HPE ProLiant MicroServer Gen10 Plus v2 E-2314 4-core 32GB-U VROC

Lifecycle

• Obsolete Date 09-05-2025

Specifications

• Memory type HPE DDR4 Standard Memory
• Product dimensions (imperial) 9.65 x 9.05 x 9.16 in
• Expansion slots 1 standard (Low Profile) PCIe 4.0, for detailed descriptions refer to the QuickSpecs
• Weight 7.5 kg
• Product dimensions (metric) 24.5 x 23 x 23.28 cm
• Warranty Server Warranty includes 1-Year Parts, 1-Year Labor, and 1-Year Onsite support with next business day response. Warranty repairs may be accomplished using Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part, 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have Hewlett Packard Enterprise replace Optional CSR parts at no charge. 3) A trained, authorized service engineer must service non-CSR parts. Additional information regarding worldwide limited warranty and technical support is available at: https://support.hpe.com/hpsc/wc/public/home NOTE: Warranty does not cover support for ClearOS. ClearCenter provides support for ClearOS.
• Optical drive type N/A
• Processor name Intel® Xeon® E-2314 (4 core, 2.80 GHz, 8 MB Intel® Smart Cache, 65W)
• Included memory 32 GB (2x 16 GB UDIMM DDR4 3200 MT/s)
• Included drives 2x HPE 1TB SATA 7.2K LFF RW MV HDD
• System fan features 1x non-redundant system fan ships standard
• Power supply type 1x 180W External Power Adapter
• Persistent memory type N/A
• Persistent memory media capacity N/A
• Processor cache 8 MB Intel® Smart Cache
• Processor core available 4 core
• Weight 16.535 lb
• Storage controller Embedded Intel VROC SATA SW RAID
• Network controller Embedded 1Gb 4-Port Intel i350-AM4 Controller
• Form factor Ultra Micro Tower
• Processor number 1 processor included
• Processor speed 2.80 GHz

Quickspecs

• QuickSpecs
• QuickSpecs (PDF)
• QuickSpecs
• QuickSpecs (HTML)

Overview

Are you a small office, home office, or small business with branch offices looking to build a customized solution for your office? The HPE ProLiant MicroServer Gen10 Plus v2 server delivers an affordable compact yet powerful entry-level server that you can customize for on-premises or for hybrid cloud possibilities. It has the same compact form factor as the previous version and can be placed flat or vertically depending on your space. Intel® Xeon® E Processor and Intel® Pentium® Gold Processor Series build compute performance as well as security and remote management into the server with HPE iLO Silicon Root of Trust from HPE iLO. Along with other enhancements such as 4 x 1GbE onboard NICs and USB 3.2 Type-A Gen2, there is nothing micro about the HPE ProLiant MicroServer Gen10 Plus v2 server.

What’s new

• Compute: Intel® Xeon® E-2314 Processor and Intel® Pentium® G6405 Processor.
• Memory: ECC, UDIMM DDR4, and 3200 MT/s (64 GB maximum).
• PCIe expansion: PCIe Gen4.
• Storage controller: Intel VROC SATA Hybrid RAID.

Features

HPE IT investment solutions help you transform into a digital business with IT economics that aligns with your business goals.

Make server deployment easy with custom RAID and setup with HPE Intelligent Provisioning and auto-intelligent RAID with HPE Rapid Setup.

Industry-Leading Services and Ease of Deployment

The HPE ProLiant MicroServer Gen10 Plus server v2 server is one of our industry-standard servers with major firmware anchored directly into the silicon security protection built-in across the server lifecycle, starting with Silicon Root of Trust.

Secure Recovery allows server firmware to roll back to the last, known-good state or factory settings after detection of compromised code.

Additional security options are available with Trusted Platform Module (TPM) to prevent unauthorized access to the server and reliably store artifacts used to authenticate the server.

More Micro and Versatile, Yet More Powerful

The HPE ProLiant MicroServer Gen10 Plus v2 server measures 4.68 in (11.89 cm) and can be placed either horizontally or vertically to fit different customer workspaces.

Powered by up to four cores in the Intel® Xeon® E Processor and up to 64 GB of 3200 MT/s DDR4 ECC UDIMM, it delivers better performance for small business applications.

HPE iLO 5 standard and essential functionality (optional), remote monitoring, restore, and maintenance are now available. [1] It is supported by installing an optional iLO Enablement kit, which includes an HPE iLO dedicated port. HPE InfoSight and HPE OneView are also supported.

Four embedded network ports provide the networking needs of small business customers. Optional 1GbE and 10GbE BASE-T and SFP+ standup option cards are supported for those who require more.

Security Innovations

HPE Services simplifies all stages of the IT journey. Advisory and Professional Services understand customer challenges and design an enhanced solution. Professional Services enables rapid deployment of solutions and Operational Services provides ongoing support.

The HPE ProLiant MicroServer Gen10 Plus v2 server comes with an available complete set of services from HPE Services, delivering confidence, reducing risk, and helping you realize agility and stability.

Services provided under Operational Services include: HPE GreenLake Flex Capacity, HPE Datacenter Care, HPE Infrastructure Automation, HPE Campus Care, HPE Proactive Services, and multi-vendor coverage.

Compatible products

• HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features
• HPE 5 Year Tech Care Essential MicroServers Smart Choice Service
• HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features
• Intel I350-T4 Ethernet 1Gb 4-port BASE-T Adapter for HPE
• HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features
• HPE 16GB (1x16GB) Single Rank x8 DDR4-3200 CAS-22-22-22 Unbuffered Standard Memory Kit
• HPE 3 Year Tech Care Basic MicroServer Smart Choice Service
• HPE 960GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• Broadcom BCM57412 Ethernet 10Gb 2-port SFP+ Adapter for HPE
• HPE 4TB SATA 6G Business Critical 7.2K LFF RW 1-year Warranty Multi Vendor HDD
• HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE Smart Array E208i-p SR Gen10 (8 Internal Lanes/No Cache) 12G SAS PCIe Plug-in Controller
• HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features
• HPE Proliant DL/ML Install Service
• HPE Proliant DL/ML Startup Service
• HPE 1TB SATA 6G Business Critical 7.2K LFF RW 1-year Warranty Multi Vendor HDD
• HPE 32GB microSD RAID 1 USB Boot Drive
• HPE 5 Year Tech Care Basic MicroServer Smart Choice Service
• HPE MicroServer Gen10 SFF-NHP Converter Kit
• HPE Mobile USB DVD-RW Optical Drive
• Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE
• HPE 3 Year Tech Care Essential MicroServers Smart Choice Service

Documents

• HPE ProLiant MicroServer Gen10 Plus v2 QuickSpecs

HPE iLO 5 standard and essential remote management features are supported when the HPE ProLiant MicroServer Gen10 Plus v2 server and HPE iLO Enablement kit are installed.
