HPE ProLiant MicroServer Gen11 E-2434 4c 32GB-U 4LFF-NHP 2x4TB HDD 180W External PS EMEA Cmp Mod Svr

Lifecycle

• Obsolete Date 30-04-2026

Specifications

• Security Trusted Platform Module (TPM) 2.0
• Power supply type 1x 180W External Power Adapter, Non-Redundant Power Supply
• Processor speed 3.40 GHz
• Processor core available 4 core
• Expansion slots 2 PCIe, for detailed descriptions reference the QuickSpecs
• Optical drive type Optional ODD Bay Kit, none included
• Form factor Ultra Micro Tower
• System fan features 1x Standard Fan
• Network controller Embedded 1GbE 4-port
• Infrastructure management HPE iLO6, dedicated iLO port included
• Processor cache 12 MB Intel® Smart Cache
• Weight 17.571 lb
• Product dimensions (metric) 37.7 x 46.7 x 25.54 cm
• Product dimensions (imperial) 14.84 x 18.39 x 10.05 in
• Weight 7.97 kg
• Processor number 1 processor included
• Warranty Server warranty includes 1-year parts, 1-year labor, and 1-year on-site support with next business day response. Warranty repairs may be accomplished using Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part, 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have Hewlett Packard Enterprise replace Optional CSR parts at no charge. 3) A trained, authorized service engineer must service non-CSR parts. For more information, visit https://www.hpe.com/support.
• Memory type HPE DDR5 Standard Memory
• Storage controller Embedded Intel® VROC SATA for HPE ProLiant Gen11
• Included drives 2x HPE 4TB SATA 6G Business Critical 7.2K LFF RW 1-year Warranty Multi Vendor HDD
• Processor name Intel® Xeon® E-2434 (4 core, 3.40 GHz, 12 MB Intel® Smart Cache, 55W)
• Included memory 32 GB (1×32 GB UDIMM, 4800 MT/s)

Quickspecs

• QuickSpecs (PDF)
• QuickSpecs (HTML)
• QuickSpecs
• QuickSpecs

Overview

Are you looking for a budget-friendly server that can fit almost anywhere? The HPE ProLiant MicroServer Gen11 delivers an affordable, compact yet powerful entry server that you can customize for on-premises or for hybrid cloud possibilities while still meeting the enterprise-class performance, security, reliability, and expandability standards of the rest of the HPE ProLiant enterprise class server portfolio. With a mini tower design, place it flat or vertically or wall mounted, depending on customer environment. The latest Intel® Xeon® 6300 Series, Intel® Xeon® E and Intel® Pentium® Processors supported to deliver compute performance, increased memory capacity, as well as security and remote management into the server with HPE iLO silicon root of trust. The affordable starting price makes the HPE ProLiant MicroServer Gen11 a good value that has the networking and performance capacity to grow with your business as your needs and budget change over time.

What’s new

• Fast OS Boot with the M.2 slot (optional slot available on the optional dedicated HPE iLO/M.2/serial port kit).
• Support for HPE iLO 6. HPE iLO remote server management support is now standard without the need of the additional module or activation key.
• Optional Serial Port (via the dedicated HPE iLO/M.2/serial port option kit).
• Four 4400 MT/s HPE DDR5 UDIMMs, offering 16, 32 GB with up to 128 GB memory capacity support.
• The latest Intel® Xeon® 6300 Series, Intel® Xeon® E-2400 and Intel® Pentium® Gold Processors.
• Two PCIe expansion slots with the new PCIe 5.0 support.

Features

Mini in Size yet still Powerful and Secure

The latest Intel® Xeon® 6300 Series, Intel® Xeon® E-2400 and Intel® Pentium® Gold Processors provide impressive performance.

Two PCIe expansion slots with the PCIe 5.0 support provide reliable scalability.

HPE ProLiant MicroServer Gen11 features iLO Silicon root of trust with server management to provide enhanced security, proven reliability and superb usability.

Embrace remote server management with HPE iLO 6.

Small, Quiet and Uniquely Designed Servers Bring the User Experience to a New Level

Optional wall mount kit provides deployment flexibility.

Offer enterprise-grade security with TPM 2.0 embedded.

HPE ProLiant MicroServer Gen11 is a powerful yet affordable server for your daily business workloads.

Proven, yet Reimagined for the Data-Driven Edge

HPE ProLiant MicroServer Gen11 features fast setup with a unique form factor that is compact and ideal for small spaces.

With four 4400 MT/s HPE DDR5 UDIMMs, it offers 16, 32 GB. and up to 128 GB memory capacity support.

Media

New HPE ProLiant MicroServer Gen11 | Chalk Talk

In this Chalk Talk, meet the new HPE ProLiant MicroServer Gen11 – mini in size yet still powerful and secure. It’s our most popular entry-level server. The video will also look at what''s new compared to the previous generation, workloads, and more.

HPE ProLiant MicroServer Gen11 for SMB

Why sacrifice power for space? The HPE ProLiant MicroServer Gen11 packs big server performance into a compact, whisper-quiet package. Perfect for tight office spaces, it’s the go-to solution for small businesses that demand enterprise-level power.

HPE ProLiant MicroServer Gen11 Product Animation

HPE ProLiant MicroServer Gen11 animated hardware tour.
