Aruba Instant On AP15 (RW) 4×4 11ac Wave2 Indoor Access Point

Lifecycle

• Obsolete Date 31-12-2099
• End of support date 31-12-2104

Specifications

• Weight 674 g
• Wi-Fi antenna Integrated downtilt omni-directional antennas with maximum individual antenna gain of 3.6dBi in 2.4GHz and 6.0dBi in 5GHz.
• Radio coverage Dual Radio for simultaneous dual-band operation 5 GHz 802.11ac 4×4 MIMO for up to 1,733 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5) 2.4 GHz 802.11n 2×2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4)
• Product dimensions (imperial) 1.6 x 7.2 x 7.2 in
• Product dimensions (metric) 41 x 183 x 183 mm
• Input voltage Power over Ethernet (POE): 802.3af (class 3) DC power (12V) Note: Power sources are sold separately
• Weight 1.5 lb
• Mounting The access point ships with a (black) mount clip to attach to suspended ceiling rails, and a (white) mount clip to attach to solid surfaces (wall/ceiling)
• Ports (1) uplink Gigabit Ethernet port, with POE-in support (802.3af)
• Warranty Aruba Instant On 2 Year warranty with 24X7 phone support for first 90 days and chat support for the entire warranty period. Community support as long as you own the products.
• Connectivity, standard IEEE 802.11ac, 802.11n
• Regulatory UL2043 plenum rating
• Certifications UL 2043 plenum rating EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments) Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3, Enhanced Open (OWE)

Quickspecs

• QuickSpecs
• QuickSpecs
• QuickSpecs (PDF)
• QuickSpecs (HTML)

Overview

Aruba Instant On AP15 Indoor Access Points deliver affordable, premium-grade Wave 2 802.11ac Wi-Fi for medium-density small business environments requiring high performance and bandwidth. Business-grade capabilities are designed to meet the mobile, IoT, and security needs of tech-start-ups and retail stores at an attractive price point. The compact form factor delivers reliable and affordable multi-user capabilities and an aggregate peak data rate of 2 Gbps to support high-definition video streaming and cloud application requirements. These Aruba Instant On AP15 Indoor Access Points (AP) also come with a built-in controller to simplify deployment, making it easy to install and manage multiple access points without requiring extensive IT experience, additional hardware, or software applications. The Aruba Instant On AP15 Indoor APs are designed for small business deployments demanding high-traffic, high-performance network environments like tech-start-ups and co-working spaces.

What’s new

• Support for WPA2/WPA3 employee and guest login with Enhanced Open for per user guest access.
• Entry-level wireless access points for small and growing businesses at a cost-sensitive price point.
• Comes with an integrated virtual controller for simple deployment of multiple access points.

Features

Simple to build landing page lets you customize your guest access page with your logo, your own brand, and acceptance of use language.

The Aruba Instant On AP15 Indoor Access Points are built with premium hardware and software quality that’s as reliable and coming from a trusted vendor.

Effortless set-up right out of the box – in the palm of your hand.

Simplicity is the Key to a Great Wi-Fi Experience
Eliminates High Cost of Cabling with Full-Scale Wireless Mesh Coverage

Create up to eight different SSIDs under one network name to keep your data safe, whether surfing the web or checking HR data.

Aruba Instant On AP15 Indoor Access Points come with integrated Wi-Fi Alliance security standard WPA2/WPA3 and Enhanced Open support for protected wireless access.

Safeguard Sensitive Data with WPA2/WPA3 and Enhanced Open

Conveniently expands your network to hard-to-wire areas while nearly eliminating rid of spotty connections and dead zones, to provide Wi-Fi where you need it.

Aruba Instant On AP15 Indoor Access Points feature built-in wireless mesh capabilities to cost-effectively extend Wi-Fi connectivity without additional cables.

Traffic for any device connecting with guest role is automatically segmented from core business traffic.

The Aruba Instant On portfolio comes with flexible management options to choose from: The Aruba Instant On mobile app guides you through step-by-step from initial set-up to ongoing management.

Fast Connectivity with 802.11ac Wave 2 Access Points that is Simple to Deploy

Aruba Instant On AP15 Indoor Access Points include an easy to use web GUI and templates so access points are up and running in minutes.

802.11ac Wave 2 features include 4×4:4SS

Dual-band wireless (2.4GHz and 5GHz) for combined speeds of up to 2Gbps support high-bandwidth activities such as video, voice, and conferencing solutions.

Aruba Instant On AP15 Indoor Access Points allow for any change to the primary AP configuration to be automatically pushed to every AP in the same cluster.

A secondary AP automatically takes over if the primary AP experiences an outage for always-on Wi-Fi.
