HPE G2 Metered Modular 3Ph 11kVA/60309 5-wire 16A/230V Outlets (6)

Lifecycle

• Obsolete Date 31-12-2024
• End of support date 31-12-2027

Specifications

• Mounting options 0U/Horizontal and 1U/Horizontal
• Power distribution Three Phase
• Weight 12 lb
• Outlet type C-19
• Weight 5.44 kg
• Product dimensions (imperial) 17.46 x 10.62 x 1.71 in
• Product dimensions (metric) 44.35 x 26.97 x 4.35 cm
• Power capacity Greater than10kVA
• Warranty Three-year limited warranty

Quickspecs

• QuickSpecs
• QuickSpecs
• QuickSpecs (HTML)
• QuickSpecs (PDF)

Overview

Do you need rack level power monitoring over the network? With billing grade accuracy, HPE G2 Metered Power Distribution Units (PDU) are an excellent choice for data centers wanting to make the most of circuit capacity or for co-location facilities needing to precisely track power usage for billing purposes. The G2 Metered PDUs offer load segment power metering and have a low profile single piece design with multiple mounting options and ease of access to rear devices for maintenance. Designed for HPE racks but also work in a large variety of third party racks as well using standard button and keyhole mounting. They can be installed on either side of the rack with outlets facing the back of the rack for easy access and improved clearance. Also for higher power density they can be installed side by side on both sides of the rack with the outlets facing in towards the center of the rack. HPE G2 Metered PDUs are backed by HPE's limited 3-year warranty.

What’s new

• HPE G2 Metered Power Distribution Units (PDU) are rated for operating temperatures of up to 60°C (or 140°F).
• Color-coded receptacles on single and three phase models to easily distinguish between the different load segments/phases.
• A hot swappable Network Management Card (NMC) allowing for power to remain distributed with the removal of the management card thus creating zero down time.
• Enhanced environmental sensor options on the G2 Metered PDUs for monitoring temperature, humidity, intrusion, and water leakage within the rack.
• Choose the optional Locking Power Cord for secure cable retention to both the PDU and target device.

Features

Powerfully Built Power Distribution, Because No Two Environments Are the Same

HPE G2 Metered Power Distribution Units (PDU) include a 3-year warranty.

Premium materials and robust construction guarantee power continuity and maintained performance at elevated temperatures.

Power distribution where you need it in the rack with Load segment metering for added management and security.

ASHRAE-certified 60-degree centigrade operating temperature (10 degrees above industry standard) means more performance and less cooling costs.

Highest-density PDUs on market means more power and less headache for even the most demanding compute applications.

Dual network access provides redundancy to protect data continuity and enable informed management decisions.

Hot swappable network management provides enables serviceability without any downtime.

HPE G2 Metered Power Distribution Units (PDU) are available in four form factors for a variety of rack configurations and environments.

Getting Power In the Right Place Has Never Been Easier, From Purchase To Prime Time

Enhanced environmental sensor options on HPE G2 Metered PDUs for monitoring temperature, humidity, intrusion, and water leakage within the rack.

Load segment metering capabilities keep you in the loop at all times – and let you shut things down if something’s amiss, from wherever you are.

Daisy-chain up to four units to share the same network connection and IP address.

Integrated cord retention to connect the right cord to the right outlet, quickly and easily.

HPE G2 Metered Power Distribution Units (PDU) are compatible with HPE IEC Locking Power Cords a new supported option available for most HPE G2 PDUs. HPE’s IEC Locking Power Cords provide a safe and secure solution against the common issues that lead to power-related downtime.

Get Power Where You Need It To Go – and Keep It There

Documents

• HPE G2 Metered Power Distribution Units QuickSpecs
